Automotive Central Control Display FPCs are an important subcategory of flexible printed circuit boards, specifically used for signal transmission and connection in automotive center console display systems. They serve as the core "nerve center" between components such as the center console screen, instrument panel, and HUD, and the vehicle's overall control and power systems. Compared to traditional rigid printed circuit boards (PCBs), automotive center console display FPCs possess core advantages such as flexibility, foldability, thinness, and lightweight design. They can adapt to the complex spatial layout of the automotive center console area, flexibly conform to the irregular structures of center console components, effectively save installation space, simplify the assembly process of the center console system, and improve production efficiency.
As one of the first enterprises in China to layout the flexible electronics industry, Honflex Electronics has been deeply engaged in the FPC field for nearly 20 years. With a complete R&D system, advanced production equipment and strict quality control, it has become a core supplier in the field of Automotive Central Control Display FPC, serving many mainstream domestic and foreign automakers and automotive electronics Tier1 suppliers. The company's Automotive Central Control Display FPCs cover various types such as single-sided boards, double-sided boards, multi-layer boards and rigid-flex boards. It can customize products of different specifications and performances according to customer needs, fully adapting to the needs of central control display systems of fuel vehicles and new energy vehicles (pure electric, hybrid), covering entry-level, mid-range, high-end and other full-scenario models, realizing the supply of "one-stop" flexible circuit solutions.
Honflex Automotive Central Control Display FPC is engineered for automotive environments, balancing flexibility, durability, and signal stability.
This Automotive Central Control Display FPC solution from Honflex is ideal for modern vehicle display systems, ensuring reliability, integration, and long-term performance.
The key technical parameters of Honflex Electronics' Automotive Central Control Display FPCs strictly follow the automotive industry standards, balancing performance and practicality. The parameters of products with different specifications can be customized according to customer needs. The core general parameters are as follows:
|
Parameter Category |
Specific Parameters |
|
Substrate Parameters |
Type:（PI）Polyimide (PI) |
|
Thickness: 0.025mm-0.1mm（Customizable） |
|
|
Copper Foil Parameters |
Type: Electrolytic Copper Foil/Rolled Copper Foil |
|
Thickness: 12μm-70μm（Customizable） |
|
|
Line Width/Spacing: Minimum 0.03mm/0.03mm（Customizable） |
|
|
Product Structure Parameters |
Layers: Customizable）1-8 Layers |
|
Total Thickness: 0.1mm-0.3mm（Customizable） |
|
|
Bending Performance Parameters |
Minimum Bending Radius: ≥0.5mm（Static） |
|
Bending Times: ≥100,000 Times（No performance attenuation after repeated bending） |
|
|
Temperature Performance Parameters |
Operating Temperature Range: -40℃~125℃ |
|
Storage Temperature Range: -55℃~150℃ |
|
|
Electrical Performance Parameters |
Signal Transmission Loss: ≤0.5dB/cm（1GHz At 1GHz Frequency） |
|
Impedance Range: 50Ω/75Ω/100Ω（Customizable） |
|
|
Impedance Deviation: ±10% |
|
|
Environmental Adaptability Parameters |
Moisture Resistance: 85%RH（40℃），No abnormality for 1000 hours |
|
Protection Level: IP65（Waterproof and Dustproof） |
|
|
Reliability Parameters |
Vibration Test: No abnormality at 10-2000Hz, 10G acceleration |
|
Impact Test: No abnormality at 50G impact force |
With excellent performance and strong customization capabilities, Honflex Electronics' Automotive Central Control Display FPCs are widely used in central control display systems of various types of vehicles, including fuel vehicles and new energy vehicles (pure electric, hybrid), adapting to entry-level, mid-range, high-end and other full-scenario models. The specific application scenarios are as follows. All application scenarios have achieved mass supply and have been highly recognized by customers:
The on-board central control screen is the core component of the automotive central control system, responsible for displaying navigation, entertainment, air conditioning control, vehicle-machine interaction and other information. Honflex Electronics' Automotive Central Control Display FPC is the core connection component between the central control screen and the vehicle machine main board and power supply system. With the characteristics of high flexibility and thinness, the product can flexibly fit the back structure of the central control screen, realize stable signal transmission, and ensure high-definition display and smooth interaction of the central control screen. The applicable central control screen types include suspended central control screen, embedded central control screen, dual-screen, triple-screen, etc., covering various sizes such as 10.25 inches, 12.3 inches, and 15.6 inches, widely used in cars, SUVs, MPVs and other types of vehicles. For example, the dual-screen central control FPC product provided by the company for a mainstream new energy automaker realizes synchronous signal transmission between the central control screen and the instrument panel, without freezing or delay, improving the user's interaction experience.
The automotive instrument panel is responsible for displaying key information such as vehicle speed, speed, fuel volume, and water temperature, and has extremely high requirements for the stability and reliability of signal transmission. Honflex Electronics' Automotive Central Control Display FPC is suitable for various types such as traditional mechanical instrument panels, liquid crystal instrument panels, and full liquid crystal instrument panels, which can realize stable signal transmission between the instrument panel and the vehicle ECU (Electronic Control Unit), ensuring real-time and accurate display of instrument panel information. The product has excellent anti-vibration and anti-electromagnetic interference performance, which can resist engine vibration and electromagnetic interference of on-board electronic equipment, avoiding problems such as display errors and signal interruption of the instrument panel. At the same time, the lightweight and thin design of the product can save the internal space of the instrument panel, helping the instrument panel upgrade towards miniaturization and integration. At present, the company's instrument panel FPC products have been mass-applied to mainstream models of many automakers, and their reliability has been verified by the market.
The HUD head-up display system can project vehicle driving information, navigation information, etc. onto the front windshield, which is convenient for drivers to view and improves driving safety. It is a mainstream configuration of high-end cars and new energy vehicles. As the core connection component of the HUD system, Honflex Electronics' Automotive Central Control Display FPC is responsible for signal transmission between the HUD display and the vehicle machine system and ECU, requiring high signal stability, high environmental adaptability and high reliability. The product can realize stable transmission of high-speed data, ensure clear and real-time projection of HUD information, and avoid problems such as blurred projection, freeze, and interruption; at the same time, the product can adapt to the installation environment of the HUD system (close to the engine compartment, high temperature and strong vibration), has excellent heat resistance and anti-vibration performance, and its service life is synchronized with the HUD system. The HUD-specific FPC product provided by the company for a high-end automaker has passed strict environmental tests, can work stably for a long time in high-temperature and vibration environments, and has been highly recognized by customers.
The on-board entertainment system (such as on-board audio, rear entertainment screen, on-board DVD, etc.) is an important component to improve the automotive riding experience, and its signal transmission quality directly affects the entertainment experience. Honflex Electronics' Automotive Central Control Display FPC can be used for signal connection of on-board entertainment systems, realizing stable transmission of audio and video signals, and avoiding problems such as audio freeze and video screen flower. The product has excellent electromagnetic compatibility, which can effectively resist electromagnetic interference in the on-board environment, ensure the purity of audio and video signals, and improve the entertainment experience. At the same time, the customization capability of the product can adapt to different types of on-board entertainment systems, providing flexible connection solutions for components such as rear entertainment screens and on-board audio. For example, the FPC product provided by the company for the rear entertainment screen of a certain automaker realizes signal synchronization between the entertainment screen and the central control system, supports high-definition video playback and audio transmission, and improves the riding experience of rear passengers.
In new energy vehicles (pure electric, hybrid), the central control display system also needs to connect core components such as battery management system (BMS) and motor control system, displaying information such as battery power, cruising range, and charging status, which has higher requirements for the performance of FPC products. Aiming at the needs of new energy vehicles, Honflex Electronics has optimized the product's high voltage resistance and anti-electromagnetic interference performance, which can realize stable signal transmission between the central control system and BMS, motor control system, ensuring the accuracy and real-time of the central control display information of new energy vehicles. The product has excellent high-temperature resistance, which can adapt to the high-temperature environment near the battery compartment of new energy vehicles, and the lightweight design can help new energy vehicles improve their cruising range. At present, the company's FPC products for new energy vehicle central control displays have been mass-applied to many mainstream new energy automakers, adapting to pure electric cars, SUVs, hybrid models, etc., providing support for the intelligent development of new energy vehicles.
As a leading enterprise in China's flexible electronics industry, Honflex Electronics has been deeply engaged in the FPC field for nearly 20 years, with a complete R&D, production, quality control and after-sales service system, providing strong support for the R&D, production and supply of Automotive Central Control Display FPCs, and is a trustworthy partner for customers:
The company has a professional R&D team, and the core R&D personnel all have more than 10 years of R&D experience in the FPC industry, covering material R&D, structural design, process optimization, reliability testing and other fields. The company has established a flexible electronics R&D center, equipped with advanced R&D equipment and simulation tools, which can quickly carry out product R&D, process optimization and performance testing. At the same time, the company pays attention to industry-university-research cooperation, has established long-term cooperative relations with many domestic universities and research institutes, and jointly carries out the R&D of core technologies of flexible electronics to improve the core competitiveness of products. Up to now, the company has hundreds of invention patents and utility model patents related to flexible circuits, and its core technologies in the field of automotive FPC are at the leading level in the industry, which can quickly respond to the technological upgrading needs of the automotive industry and provide customers with forward-looking product solutions.
The company has a modern production base, equipped with advanced production equipment imported from abroad, covering the entire production process of substrate cutting, copper foil lamination, etching, lamination, drilling, welding, testing, etc., realizing automatic and precision production of products. Among them, etching equipment, lamination equipment, testing equipment, etc. have reached the international advanced level, which can ensure the production precision and consistency of products; the application of automatic production lines not only improves production efficiency, but also reduces human operation errors and improves product qualification rate. The company's production base has passed ISO/TS 16949 automotive industry quality system certification and ISO 14001 environmental management system certification, realizing standardized and standardized management of the production process, which can meet the strict requirements of the automotive industry for product quality and production stability. At the same time, the company has large-scale mass production capacity, with an annual output of tens of millions of square meters, which can meet the mass supply needs of customers.
The company has established a complete quality control system, strictly following the ISO/TS 16949 automotive industry quality system standard, realizing full-process quality control from raw material procurement, production process control to product factory testing. In the raw material procurement link, the company strictly screens the suppliers of core raw materials such as substrates, copper foil, and ink, and establishes a supplier evaluation system to ensure that the quality of raw materials meets the requirements; in the production process, multiple quality
